2. After the turntable is in position, remove the plastic gearbox cover plate
by loosening the four plastic bolts holding it in place.
If you are installing the shaft kit, disregard the remainder of the instructions in
this section and skip to Optional Shaft Kit Installation Instructions on page 23.
3. Install the aluminum shaft adapter onto the black shaft from the turntable
gearbox. Use the 1/4-in phenolic (brown plastic) pin to key it to the black
shaft. A spacer piece fits inside the shaft adapter and between the
adapter and phenolic pin to secure the pin into place.
Two 8–32 set screws lock the adapter into place onto the shaft.
4. Slip the gray hose coupling with the two hose clamps onto the shaft
adapter.
5. An aluminum bracket holds the motor drive to the turntable base. The
bracket attaches to the 3/4-in base plate of the turntable using
two 1/2–13 x 3/4-in bolts. Two standoffs attach the bracket to the
motor base at the correct distance.
6. Position the motor drive so the shaft slips into the hose coupling. The
bracket installed in step 5 should now be in place. Secure the bracket to
the motor base using the provided 1/4-in x 1 1/4-in hex head cap screws.
Tighten both hose clamps to secure the gray hose coupling around the
shafts.
7. Place the gearbox cover on the gearbox, and then insert and tighten the
four bolts.
