Assembly and Installation | 21
6.0 Assembly and Installation
Before assembling, installing, or connecting any components,
follow the safety information in the ETS-Lindgren
Product Information Bulletin included with your shipment.
Prior to assembly and installation, review the drawings located in the back
pocket of this manual.
The Model 2165 LoPro™ Turntable is shipped partially assembled, and
additional assembly is estimated to take a maximum of one hour. Make sure a
clear area is available to unpack, assemble, and install the turntable. Prior to
assembly, open the shipping container and check all parts for any shipping
damage.
Do not discard any packing material until the turntable is fully installed and
operational.
Required Tools
• Level
• Adjustable
wrench
• Phillips screwdriver and flat head screwdriver
• Shims, if the floor surface is not level
Assembly Instructions
Make sure power is off and secured before proceeding.
1. Position the turntable mechanical assembly on the floor. The turntable
mechanical assembly has a 44-in (112-cm) base plate that must rest on
a flat surface. For proper alignment of the drive shaft, the bottom surface
of the turntable mechanical assembly, the drive shaft assembly, and the
motor drive assembly must all be installed at the same level. If the floor
is not flat, it may be necessary to place shims under the base. The
turntable will stay in place due to its own weight, but the base plate
provides four holes used to fasten the unit to the floor with 5/16-in
diameter screws.
