Optional Shaft Kit Installation Instructions | 23
7.0 Optional Shaft Kit Installation Instructions
Before assembling, installing, or connecting any components,
follow the safety information in the ETS-Lindgren
Product Information Bulletin included with your shipment.
If you are not installing the shaft kit, disregard the instructions in this section
and skip to Operation on page 29.
The shaft kit allows the motor base to be positioned up to 5 m (16.4 ft) from the
turntable. The drive shaft assembly includes an inner shaft mounted in an outer
housing supported in the center and at each end by plastic floor supports.
This section provides assembly information for the shaft and instructions to cut
the shaft components if a shorter distance between the motor base and turntable
is required. Following is an overview of steps:
1. Determine shaft length—see page 24.
• Cut drive shaft assembly (may not be required)—see page 27.
• Cut shaft housing (may not be required)—see page 28.
2. Assembly drive shaft—see page 22.
3. Install shaft housing—see page 25.
4. Install drive shaft—see page 25.
5. Connect shaft to motor drive—see page 26.
Components
Part Quantity
Shaft sections 2
Shaft coupler 1
1/4–20 self-tapping screws 4
End floor supports, with a single clamp for a single item 2
Mid-floor support, with a double clamp for two items 1
Shaft housings, 4.5-in diameter 2
White bushings, one for each end of the shaft housing assembly
and one for the center between the two shaft housing components
3
