24 | Optional Shaft Kit Installation Instructions
Required Tools
In addition to the tools for basic installation, these additional tools are required:
• Tape
measure
• Drill
•
Assorted bits, including 7/32
•
Hand or reciprocating saw
• Marker
• File/sandpaper
Determine Shaft Length
To install the shaft kit, determine the DIM1 dimensions as shown on Drawing 4
located in the back pocket of this manual. This is the distance from the center of
the turntable top to the end of the drive shaft floor support.
If DIM1 needs to be shorter than the standard 5 m (16.4 ft), you must cut the
drive shaft assembly to the proper length before attaching it to the turntable. See
Cut Drive Shaft Assembly on page 27 for complete instructions.
No cutting is required if the standard length is acceptable for installation.
However, the shaft must be the correct length before proceeding.
Assemble Drive Shaft
See Drawing 8 located in the back pocket of this manual.
To assemble the two sections (section A and section B) of the drive shaft using
the provided coupling: Insert the 6.0-cm (2.37-in) diameter plain ends of the shaft
sections into the coupling all the way to the step. Match drill the shaft sections
through the four pre-drilled holes in the coupling and install the
four 1/4–20 self-tapping screws provided.
