Specifications

|

15

3.0 Specifications

Electrical Specifications

Nominal AC Voltage:

208–230 VAC

Input Frequency:

50/60 Hz

Current Rating:

3 A

RPM:

0.5 – 2.5

Phase:

Single

Motor Horsepower:

1/4 HP

Physical Specifications

Turntable Diameter:

1.2 m (3.94 ft)

Nominal Height:

5 cm (1.97 in)

Nominal Load Capacity:

273 kg (601.86 lb)

Nominal Max Diameter:

1.2 m (3.94 ft)

Top Construction:

One-piece PVC

Distributed Load Rating

:

273 kg (600 lb)

Distributed Load Rating applies when:

• Load is evenly distributed on top;

• No point loads under 0.19 sq m (2.0 sq ft) should exceed 100 kg

(220 lb);

• And not over 28.5 kg (62.8 lb) should be applied to a 45-degree

segment at the table outer edge.
