X G 2 T E S T O S C I L L A T O R M A N U A L E R R A T A

Rev F-1, July 31, 2012

T H E F O L L O W I N G C H A N G E S T O T H E X G 2 M A N U A L

M U S T B E M A D E B E F O R E P R O C E D I N G ,

O R T H E X G 2 M O D U L E W I L L N O T F U N C T I O N C O R R E C T L Y

1. Page 1 ONLY, Parts Inventory: This section of the parts list replaces the one in the manual on page 1: (You

can cut this out and pasted it in the manual.)

Ref Qty

Description

Part

#

R2

1 Res, 18.7 k 1% (brn, gry, vio, red, brn)

E500127

R3 1

Res,

16.5

Ω 1% (brn, blu, grn, gold, brn)

E500122

R4 1

Res,

348

Ω 1% (org, yel, gry, blk, brn)

E500123

R5 1

Res,

57.6

Ω 1% (grn, vio, blu, gold, brn)

E500124

R6, R7

2 Res, 52.3 Ω 1% (grn, red, org, gold, brn)

E500125

R8

1 Res, 1.24 k 1% (brn, red, yel, brn, brn)

E500126


2. Page 8, Schematic Diagram: Change the value of R8, near the right end, from 1270 to 1240.
