2
Ref Qty Description Part #
R1, R9 2 Res, 10 k 5% (brn, blk, org) E500015
R13 1 Res, 5.6K 5%, (grn,blu,red) E500007
C2, C5 2 Mono Cap, 47 pF (47 or 470) E530014
C1 1 Mono Cap, 18 pF (18 or 180) E530212
C3, C4 2 Mono Cap, .047 µF (473) E530131
C6 1 Mono Cap, 33 pF (33 or 330) E530013
D5 1 Red LED, round E570025
D2 1 Red LED, rectangular E570007
D1, D4 2 Diode, 1N4148 E560002
U1 1
Ref. Diode, 1.22 V, ZXRE125DR or
ZXRE1004D
E600081
Q1 1 Transistor, 2N3904 E580017
X1 1 Crystal, 14060 kHz E850211
X2 1 Crystal, 7040 kHz E660023
X3 1 Crystal, 3579.545 kHz E660029
BT1 1
Lithium 3V battery, CR2032 (Inside envelope
E850058)
E980039
S1 1 Miniature slide switch E640009
J1 1 BNC Connector E620020
S2 1 Large slide switch E640019
S3 1 Rotary switch, 3 position E640027
Misc. 3 Self-adhesive mounting feet E700024
Misc. 1 Battery Holder E980086
Misc. 1 XG2 Printed Circuit Board E100255
Assembly

Sort the resistors by value. Some of the color bands may be hard to read; use a
magnifying glass if necessary. A Digital Multimeter (DMM) should be used to confirm
the values.
