Parts Inventory
i
Caution: Diodes D1 and D2 can be damaged by static discharge. Before handling
these parts, put on an anti-static wrist strap or touch any grounded, unpainted metal
surface.
The table below lists all parts in the kit. The KX1 Owner's manual has photographs of similar parts.
Ref. Description Qty Part No.
C3 Capacitor, 68 pF ("68" or "680") 1 E530150
C4, C5 Capacitor, 0.1 µF ("104") 2 E530020
C1, C2 Capacitor, 1-40 pF trimmer 2 E540002
D1, D2 Diode, PIN, precision, 5082-3081 (glass) 2 R560014
R4, R5 Resistor, 1 k, 1/8-W, 5% (brown-black-red) 2 E500116
L1, L2, L3 Miniature RF choke, 47 µH (yellow-violet-black)
Note: L1-L3 may be labeled R1-R3 on the PC board.
3 E690043
MISCKXAT1 PC board 1 E100184
MISCSolid, insulated hookup wire, green 1 ft. E760008
MISCRubber bumper, .04" thick x 0.3" square 2 E980017
Parts Placement Drawing
A drawing showing the locations of components on the KXB30 board can be found in Appendix F of the
KX1 Owner's Manual.
