SECTION III: PARTS IDENTIFICATION
PAGE 6
HZ1J
HZ1K
HZ1O
HZ1P
HZ1L
HZ1M
HZ1Q
HZ1R
H25C
HZ1N
CLR.
BRZ.
CLR.-LH
CLR.-RH
BRZ.-LH
BRZ.-RH
CLR.-LH
CLR.-RH
BRZ.-LH
BRZ.-RH
REGENT BOTTOM PIVOT
REGENT INTERMEDIATE OFFSET
PIVOT
REGENT TOP PIVOT
(TOP PIVOTS ARE NOT HANDED)
IHP2 -1/4"-20 X 3/4"HX-MS 18-8 PULL HANDLE ATTACHMENT
M104 -1/4"-20 X 2 1/4" PL-TH-MS 18-8 BOLT FOR PUSH BAR
M105 -1/4"-20 X 2 1/2" HX-MS 18-8 THRU BOLT FOR PUSH BAR
ATTACH.
IHP2 - 1/4" - 20 X 3/4"HX-MS 18-8 PULL HANDLE ATTACHMENT
M104 - 1/4" - 20 X 2 1/4" PL-TH-MS 18-8 BOLT FOR PUSH BAR
M105 - 1/4" - 20 X 2 1/2" HX-MS 18-8 THRU BOLT FOR PUSH BAR
ATTACH.
DESCRIPTION
TOP, BOTTOM, AND INTERMEDIATE OFFSET PIVOT FRAME PORTIONS
DESCRIPTION
F528 - 1 - 4" X 4 1/2" BUTT HINGE BACKER PLATE
M108 - 4 - #12-24 X 3/4" PL-FH-MS 18-8 OX
# / QUANTITY / DESCRIPTION
F528 - 1 - 4" X 4 1/2" BUTT HINGE BACKER PLATE
M100 - 4 - #12-24 X 3/4" PH-FH-MS 18-8
K900 CLR.
K901 BRZ.
CLR.
BRZ.
BLK.
K415
K416
K417
FINISH/HANDED PART #
K418
K419
K420 CLR.
BRZ.
BLK.
PUSH/PULL PACKAGES
PART # FINISH DESCRIPTION
HY90 CLR.
HY92 BRZ.
BUTT HINGE BACKER PACKAGES
FINISH PART #
BUTT HINGE PACKAGES
PART # FINISH
4" X 4 1/2" BUTT HINGES
36" TO 48"
LEAF SIZES
36" & BELOW
LEAF SIZES
DPS NOV. 2003 TIE ROD DOORS
(CONT.)
