SECTION III: PARTS IDENTIFICATION
PAGE 5
T300
(3 1/2"
TOP RAIL)
T200/T300
(7 1/2"
BOTTOM
RAIL)
H348 1" SETTING BLOCK
H159 1/4" SETTING BLOCK
PART #
10" BOTTOM RAIL ADAPTOR PACKAGE
HB19 1" OFFSET JACK SCREW CAP
HB18 1/4" OFFSET JACK SCREW CAP
K421 T200
K432 T300
BOTTOM
RAIL
ADAPTORS
TOP RAIL
ADAPTORS
PART #
NOTE: SEE PAGE 9 FOR APPROPRIATE APPLICATION.
FT29 - 10" BOTTOM RAIL ADAPTOR
FT30 - 10" BOTTOM RAIL ADAPTOR CLIP
MS01 - #12-24 X 1/2" PL-PH-MS 18-8
S123 - #12-24 X 3/4" PH-FH-SMS 18-8 F
K459
T200
T300
STILE
FS77
T200
(4"
BOTTOM
RAIL)
DPS/BB NOVEMBER 2000
# / DESCRIPTION
FT03
# / DESCRIPTION
HB17 - OFFSET JACK SCREW BLOCK
WM62 - FOAM SPRING BLOCK
M103 - OFFSET JACK SCREW 1/4"-20 X 2" HX-MS
HB17 - OFFSET JACK SCREW BLOCK
WM62 - FOAM SPRING BLOCK
IHP2 - OFFSET JACK SCREW 1/4"-20 X 3/4" HX-MS
T200
(2 3/8"
TOP RAIL)
PART #
FS76
STILE
STILE
PART #
FT13
STILE
FS75 TIE ROD WASHER
IQT1 3/8"-16 SERRATED LOCK NUT
M120 36" TIE ROD
M151 48" TIE ROD
DETAIL PART # DESCRIPTION/ PARTS IN PACKAGE
OFFSET JACK SCREW ASSEMBLY
(TR200 ONLY)
