DEGLAZING TOOL
PART #HM47
Stalgard is a registered trademark of Textron, Inc.
MOLDED CORNER DART
deglazing tool provided directly between the gasket intersection point, at the
of the glass until the corner dart pops out of the gasket retainer pocket.
If the glazing must be removed, use the following procedure. Insert the
corner. Insert the point of the tool directly down until the point hits the
back of the vertical gasket retainer pocket. Using a prying motion, rotate the
out against the back of the molded corner dart. Pry the tool toward the face
push the tool inward and pull gently outward on the gasket to facilitate
reposition the tool under the continuous dart. Using the same prying motion,
Using your free hand, hold the gasket back and away from the wall and
plane of the wall. Never twist the gasket when pulling it out as this may
NOTE: Always pull the gasket gently, directly out, and perpendicular to the
cause the material to tear or cut the gasket dart legs.
point of the deglazing tool until the curved back portion seats against the
gasket retainer pocket. This action will allow the point of the tool to press
SECTION X: DEGLAZING PROCEDURE
STEP #1 GASKET REMOVAL
removal.
A
UNDER THE DART IN THE CORNER
POSITION THE DEGLAZING TOOL
DART PRIOR TO REMOVING THE
OF THE GASKET. DISENGAGE THE
GASKET.
A
VIEW A-A
