EFCO E-Shade User Manual
Page 35
SERIES 5600 CENTER TONGUE SUNSHADE CLIP INSTALLATION MANUAL 6/2012
EFCO CORPORATION
PART #YWSS Page 35 of 41
SECTION XIII: SUNSHADE CLIP ATTACHMENT UTILIZING
BUTT JOINTED 2½” OUTRIGGER CLIP
LOCATE & PLACE
LOWER PRESSURE
PLATE W/ TYPICAL
GASKETS INSTALLED.
NOTE:
TOP OF LOWER PRESSURE
PLATE SHOULD BE 6½” BELOW
THE CENTERLINE OF THE
SUNSHADE OUTRIGGER CLIP.
