SERIES 5600 CENTER TONGUE SUNSHADE CLIP INSTALLATION MANUAL 6/2012
EFCO CORPORATION PART #YWSS Page 25 of 41
SECTION X: SNAP-ON CONTINUOUS BULLNOSE
COVER
SNAP-ON THE BULLNOSE COVER: DEPENDING ON THE LENGTH OF
THE RUN AND THE ACCURACY OF SUNSHADE LADDER LEVELING
ALIGNMENT; USE OF “C” CLAMPS MAY BE NECESSARY. BE
CAREFUL TO PROTECT THE FINISH FROM BEING MARRED BY THE
“C” CLAMPS AS THEY ARE TIGHTENED TO ENGAGE THE SNAP. ON
LONG RUNS, IT IS HIGHLY RECOMMENDED TO PIN THE COVER BY
MATCH DRILLING THROUGH THE TOP-SIDE SNAP AND RUNNING
A COUPLE OF #6 SCREWS NEAR THE MID-POINT OF THE RUN.
