SERIES 5600 CENTER TONGUE SUNSHADE CLIP INSTALLATION MANUAL 6/2012
EFCO CORPORATION PART #YWSS Page 34 of 41
SECTION XII: SUNSHADE CLIP ATTACHMENT AT
VERTICAL 90 DEGREE MULLION
END OF INSTRUCTION
TORQUE THE THROUGH BOLTS TO 80
IN/LBS. AND SEAL THE VOID AROUND
THE CLIP AND MULLION WITH SEALANT.
AFTER THE 90 DEGREE CORNER
SUNSHADE CLIP IS SECURELY
ATTACHED, THE WALL IS NOW
READY FOR COMPLETION IN
ACCORDANCE WITH THE
STANDARD CURTAIN WALL
INSTALLATION INSTRUCTIONS.
