SERIES 5600 CENTER TONGUE SUNSHADE CLIP INSTALLATION MANUAL 6/2012
EFCO CORPORATION
PART #YWSS Page 10 of 41
SECTION III: SUNSHADE CLIP ATTACHMENT
LOCATE & INSERT SUNSHADE CLIP INTO THE PRESSURE PLATE SLOT,
AND FASTEN TO THE VERTICAL MULLION WITH THE APPROPRIATE
QUANTITY & TYPE OF FASTENERS AS RECOMMENDED. [BASED ON
STRUCTURAL REVIEW & PER THE SHOP DRAWINGS]
