SERIES 5600 CENTER TONGUE SUNSHADE CLIP INSTALLATION MANUAL 6/2012
EFCO CORPORATION
PART #YWSS Page 32 of 41
SECTION XII: SUNSHADE CLIP ATTACHMENT AT
VERTICAL 90 DEGREE MULLION
INSERT CORNER SUNSHADE CLIP
IN MULLION SLOT AS SHOWN,
ROTATE DOWN AS SHOWN TO
ALIGN HOLES IN CLIP WITH
HOLES IN THE MULLION.
