Tuning Link User Guide
C H A P T E R 2
Basic Software Features
2-18
If you allow the TP value outside the allowed error for that Target TP, the run will
end and the software will return the bike’s RPM to the start point you selected.
Upon completion of the run, an air/fuel ratio (AFR) vs. RPM graph will appear in
the window. The following is an example of a typical first run AFR graph.
Figure 2-17: Roll-On Tuning—First Run AFR Graph
2
To make changes to the graph, press Enter or click on the graph. You will see the
software change some of or all of the values in the column you are tuning.
Figure 2-18: Roll-On Tuning—Changes To The Fuel Map
changed values
