Tuning Link User Guide
C H A P T E R 2
Basic Software Features
2-16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BASIC SOFTWARE FEATURES
The Tuning Link software operates in three different modes; these modes are
available only when load control is turned on. Each mode is described below.
B IKE B REAK - IN /W ARM U P
Select Mode ! Bike Break-in/Warm Up
Warm Up mode allows you to bring the dyno, bike, and any other equipment (air/fuel
sensor, etc.) to the proper operating temperature. The brake is active in this mode
and may be used to load the bike until it reaches operating temperature. Warm Up
mode is critical since many bikes will operate differently when they are too cold.
While in this mode, the software will not attempt to make any fuel changes.
Note: If you tune the bike when it is too cold, the bike may not run properly once
it has reached operating temperature.
S TEADY S TATE F UEL M APPING
Select Mode ! Steady State Fuel Mapping
Steady State Fuel Mapping, or Steady State Tuning, mode allows you to tune specific
portions of the map using the eddy current brake to hold the bike steady at a
particular RPM while you control the throttle position (TP). Steady State Tuning mode
is particularly useful for tuning cruise modes to achieve optimum fuel mileage. This
mode is also used to fix problem areas in the low RPM ranges that occur on modified
high-revving sport bikes.
While in Steady State Tuning mode, you can expect to see one of the following
behaviors. These behaviors allow different styles of tuning but will achieve similar
results.
• When the Max Steady State TP is set to a value higher than the current TP value, the
software will tune the current cell and move to the cell directly to the right of the
current cell and continue tuning horizontally across each row. After tuning the last
cell at the end of the row (Current TP equals Max Steady State TP), the software
will move to the first cell of the next row.
Figure 2-14: Steady State Tuning—Max Steady State TP Set Higher Than Current TP
config window—max
steady state TP value
tune current cell
tuning will continue
horizontally across each row
