System Common Messages
Status Second Third Description
1111 0010 0vvvvvvv 0vvvvvvv Song Position Pointer – LS Byte then MS Byte.
Positions depends on Clock Divide. For example,
if Clock Divide is set to 4n (quarter note), then
the sequence is 4 measures of 4/4 in length. The
Song Position will calculate correctly within the
four bars.
System Real-time Messages
Status Description
1111 1000 Timing Clock
1111 1010 Start – starts the sequencer from step 1
1111 1011 Continue – re-starts the sequencer from the current step
1111 1100 Stop – Stops the sequencer
Universal System Exclusive Message (Device Inquiry)
Status Description
1111 0000 System Exclusive (SysEx)
0111 1110 Non-realtime message
0vvv vvvv If MIDI channel is set to 1-16, 0vvvvvvv must match (unless MIDI Channel
= ALL); always responds if 0vvvvvvv = 0111 1111.
0000 0110 Inquiry Message
0000 0001 Inquiry Request
1111 0111 End of Exclusive (EOX)
Evolver responds with:
Status Description
1111 0000 System Exclusive (SysEx)
0111 1110 Non-realtime message
0vvv vvvv If MIDI Channel = ALL, 0vvvvvvv = 0111 1111. Otherwise 0vvvvvvv =
Channel Number 0-15.
0000 0110 Inquiry Message
0000 0010 Inquiry Reply
0000 0001 DSI ID
0010 0001 Poly Evolver ID (Family LS)
0000 0000 Family MS
0000 0000 Family Member LS
0000 0000 Family Member MS
0jjj nnnn Main PIC Software version: jjj – Major rev; nnnn – Minor Rev
0jjj nnnn Voice PIC Software version: jjj – Major rev; nnnn – Minor Rev
