Dave Smith Instruments POLY EVOLVER KEYBOARD - Manual (Page 20)

MIDI Program:xxx
MIDI Pressure:xx
MIDI Program: Off, On – When On, the Poly will respond to MIDI program changes
received, and will transmit Program changes to MIDI Out.
MIDI Pressure: Off, On – When On, the Poly will respond to MIDI pressure
(aftertouch) received, and will transmit Keyboard Pressure to MIDI Out.
Page 6:
MIDI Control:xxx
MIDI SysEx:xx
MIDI Control: Off, On – When On, the Poly will respond to MIDI controllers, and will
transmit controllers from the keyboard to the MIDI Out. Controllers include Pitch
Wheel, Mod wheel, Pedal 1, and pedal 2.
MIDI SysEx: Off, On – When On, the Poly will respond to MIDI SysEx messages,
and will transmit them from the keyboard to the MIDI Out. Note that all
knobs/parameters on the keyboard are sent as SysEx messages when enabled.
Page 7:
Input Gain:xxxxx
LCD Contrast: xx
Input Gain: 0db… 24d – Provides extra gain on the Left and Right External Inputs.
You can select no gain (0 dB), or a gain in steps of 3 dB up to 24 db.
LCD Contrast: 1…100 – This sets the contrast level for the LCD. Normally it will be
around 15.
Page 8:
Pedal 1:xxxxxxxx
Pedal 2:xxxxxxxx
Pedal 1: see table – Sets the destination for the Pedal/CV1 input. Note that this input
is heavily filtered for clean operation, so there is a limit to the speed it will respond to
an external control voltage.
Pedal 2: see table – Same for Pedal/CV 2.
Display Pedal Routing
FootCtrl Routed to the Foot Control Modulation
Breath Routed to the Breath Control Modulation
Expressn Routed to the Expression Modulation
Volume Controls Master Volume
LpFilter Routed to the low pass filter
20
