Decay: 0…110 – Sets the Decay time.
Sustain: 0…100 – Sets the Sustain level.
Release: 0…110 – Sets the Release time.
Audio Mod: 0…100 – Sets the amount of audio modulation from the analog oscillator
to the filter, separate in left and right channels; i.e. Oscillator 1 modulates the left filter,
and Oscillator 2 mods the right filter.
L/R Split: 0…100 – Split separates the cutoff of the left and right filters by raising the
left and lowering the right. Normally the filters track in both channels, so this
parameter provides a way to unlock them.
Amplifier
VCA Level: 0…100 – Sets a base level for the VCA (Voltage controlled Amplifier).
This allows the VCA to be essentially bypassed, which may be necessary for
processing external audio signals, or for Programs that drone.
Note: If VCA Level is on full, Envelope Amount has no effect.
Env Amount: 0…100 – Sets the amount of VCA envelope to the VCA level.
Velocity: 0…100 – Sets the amount of MIDI velocity controlling the level of the VCA
envelope.
Attack: 0…110 – Sets the Attack time of the VCA ADSR envelope generator.
Decay: 0…110 – Sets the Decay time.
Sustain: 0…100 – Sets the Sustain level.
Release: 0…110 – Sets the Release time.
Output Pan: see table – Sets output panning. This affects the feedback; it allows
signal from one channel to feedback into the other, for example.
Display Output Pan Selection
LxxxxR Stereo 1 – Left channel panned fully left, Right fully to the
right
xLxxRx Stereo 2 – Left channel panned mostly left, Right mostly to
the right
xxLRxx Stereo 3 – Left channel panned somewhat left, Right
somewhat to the right
