49
Transmitted Controller Messages
Status Second Third Description
1011 nnnn 0000 0111 0vvvvvvv Volume knob
1011 nnnn 0010 0000 0vvvvvvv Bank Select — 0 to 2
See sections below for additional Continuous Controller (CC) and Non-
registered Parameter Number (NRPN) messages transmitted.
Additional Continuous Controllers
(CCs) Transmitted/Received
The following table details how CCs are mapped onto Tetra’s controls. They are
transmitted when MIDI Parameter Send is set to CC in Global, and recognized
when received when MIDI Parameter Receive is set to either CC or All in
Global.
Parameter CC
OSC 1 FREQ 20
OSC 1 FREQ FINE 21
OSC 1 SHAPE 22
GLIDE 1 23
OSC 2 FREQ 24
OSC 2 FREQ FINE 25
OSC 2 SHAPE 26
GLIDE 2 27
OSC MIX 28
NOISE LEVEL 29
SUB OSC 1 LEVEL 30
SUB OSC 2 LEVEL 31
FEEDBACK VOLUME 52
FEEDBACK GAIN
53
FILTER FREQ 102
RESONANCE 103
FIL KEY AMT 104
FIL AUDIO MOD 105
FILTER ENV AMT 106
FIL ENV VEL AMT 107
FIL DEL 108
FIL ATT 109
FIL DEC 110
FIL SUS 111
FIL REL 112
VCA LEVEL 113
OUTPUT PAN 114
VCA ENV AMOUNT 115
AMP ENV VEL AMT 116
VCA DEL 117
VCA ATT 118
VCA DEC 119
VCA SUS 75
VCA REL 76
ENV3 DEST 85
ENV3 AMT 86
ENV 3 VEL AMT 87
ENV 3 DELAY 88
ENV3 ATT 89
ENV3 DEC 90
ENV3 SUS 77
ENV3 REL 78
TEMPO 14
TIME SIG 15
