47
MIDI Implementation
Tetra receives MIDI data according to the mode controls under G
LOBAL
. In
addition, there is interaction between some of the program parameters that
determine the overall response of Tetra to MIDI data. Note that the following
applies to using both the MIDI jacks and USB.
Following are the Global parameters that affect response to MIDI:
MIDI Channel: ALL, 1…16 — Selects the MIDI channel to send and receive
data, 1 to 16. All receives on any channel.
Clock: see table — Selects the MIDI clock status as follows:
Display MIDI Clock Setting
Internal MIDI clock is neither sent nor received
MIDI Out MIDI clock is sent
MIDI In MIDI clock is received
MIDIn/Out MIDI clock is received and transmitted
MIDI Parameter Send: NRPN, CC, Off —
Changes to the values of Tetra’s front
panel controls are transmitted via MIDI as Non-registered Parameter Number
(NRPN) controllers or as Continuous Controllers (CC). Transmission of
parameters can also be turned off.
MIDI Parameter Receive: All, NRPN, CC, Off — Sets the method by which
Tetra receives parameter changes via MIDI. As with transmission, NRPNs are
the preferred method, though some controllers may only be able to send CCs.
MIDI Control: Off, On — When On, the synth will respond to MIDI controllers,
including Pitch Wheel, Mod Wheel, Pedal, Breath, Volume, and Expression.
MIDI SysEx: Off, On — When On, the synth will respond to received MIDI
SysEx messages, and will transmit them, when prompted, to the MIDI Out.
MIDI Messages
System Real-time Messages
Status Description
1111 1000 MIDI Timing Clock
