Coral Industries Provincial Prestige Swing Door/ILP - 0PJ - Manual (Page 6)

0PJ 6/02
OUTSIDE OF SHOWER
Door Panel
Sill A
Caulk
On opening side of door, caulk joint on sill
where magnetic door stop and sill meet.
Double
Channel
E
Magnetic
Door Stop
OUTSIDE OF SHOWER
Caulk
Sill
A
D
The use of a caulking compound will assure a water-tight seal
of your enclosure. Apply caulk along outside edge of enclosure
where metal and shower meet, especially where sill meets
threshold.
If desired, caulk inside of enclosure where jambs meet walls.
14
Caulk
OUTSIDE OF SHOWER
Side
Panel
On opposite side, caulk where hinge door
stop and sill meet.
12
Make certain that bottom channel of door is clean and dry before mounting drip rail. After mounting,
drip rail should not be removed or repositioned. Adhesive on tape needs 72 hours curing time for
maximum bond.
Aluminum drip rail may be additionally secured by
drilling with 1/8" drill bit through drip rail into bottom
channel. Attach using 8A x 3/8" truss head screws.
When drilling in door panel, make sure drill does not hit
glass. Glass is seated approximately 1/2" into channel.
With door in closed position, place drip rail on bottom channel
of door on inside of shower. Position so that bottom edge of
sweep extends approximately 1/2" below bottom of door.
Mark location for drip rail, peel protective cover from tape (M)
and press into place.
Insert drip rail plug (P) into groove of drip cap on opening side
of door.
P
Drip Rail
Tape
F
M
INSIDE OF SHOWER
Drip Rail Plug
1/2"
Sweep extends
1/2" below
bottom channel.
Door
Panel
Drip
Rail
13
