Ja k – Coral Industries Double Swing Door - Hyaline Series - 6X0 (Detailed Installation Instructions) User Manual
Page 3
6X0-GP 7/06
A070
HEADER
OUTSIDE OF SHOWER
I
HTG6
PUSH/PULL
HANDLE KIT
H900
SELF-DRILLING
PAN HEAD SCREW
K
V678
VINYL
DOOR
SEAL
(Pre-Installed)
A083
JAMB
MAGNETIC
CLOSURE KIT
EXTERIOR
HANDLE
V
M
H002
ANCHOR
A001 SILL
(Use is optional)
V001 VINYL
DRIP SWEEP
F
G
H480
PAN HEAD
SCREW
C
A716
HEADER INSERT
D
A954
MAGNETIC STOP
E
H437
SELF-DRILLING
PAN HEAD SCREW
H
INTERIOR
HANDLE
B
Care should be taken when standing raw glass on its edge. Glass may shatter if corners are bumped or edge is
rested on a rough floor surface. Cardboard, wood blocks, or a similar surface is a safe resting surface for glass.
W
V002
H-SEAL
SPLASH GUARD
(Use is optional)
J
A
K
8A x 3/8 Self-Drilling Pan
Head Screw
(H900 - Used for securing
Hinge Rails to Jambs)
J
8A x 5/8" Self-Drilling Pan
Head Screw
(H437 - Used for securing
Magnetic Stop to Header,
Header to Jambs)
G
8A x 1 1/4" Pan Head
Screw
(H480 - Used for securing
Jambs to walls)
