6X0-GP 7/06
PARTS LIST
KEY DESCRIPTION PART QTY
A SILL (Use is optional) A001 1
B JAMB A083 2
C HEADER A070 1
D HEADER INSERT A716 2
E MAGNETIC STOP A954 1
F VINYL DRIP SWEEP V001 2
V VINYL DOOR SEAL (Pre-Installed) V678 6
W H-SEAL SPLASH GUARD (Use is optional) V002 1
G 8A X 1 1/4" PAN HEAD SCREW H480 8
H ANCHOR H002 8
I PUSH/PULL HANDLE KIT HTG6 2
PLASTIC WASHER 8
EXTERIOR PULL HANDLE 2
INTERIOR PULL HANDLE 2
BUSHING 4
HANDLE CONNECTOR SCREW 4
M MAGNETIC CLOSURE KIT HKMADCH 2
MAGNETIC CLOSURE WITH MAGNET HMAH / HG92 2
VINYL V208 2
STRIKE PLATE HA75 2
J 8A X 5/8" SELF-DRILLING PAN HEAD SCREW H437 4
K 8A X 3/8" SELF-DRILLING PAN HEAD SCREW H900 10
FRAME PACKAGE
TOOLS NEEDED
1/8" Drill Bit
(3/16" Masonry Bit for
Ceramic Tile)
Pencil
Measuring Tape
Hacksaw
Phillips Screw Driver
Silicone Caulk
File
Drill
Level
Masking Tape
Scissors
HARDWARE BAG
Before starting installation of your new enclosure, carefully read all instructions and lay out parts to become familiar
with their identity. Installation is a manageable task for an experienced "Do-It-Yourselfer" and a helper.
Frameless patch-hinge doors, by nature of their design, are not completely watertight.
USE OF ANCHORS
Anchors are furnished with every enclosure. However, the use of anchors is not recommended when attaching your enclosure
to a fiberglass unit or wall surrounds with board reinforced mounting areas. Mounting holes in this case should be drilled with
an 1/8" drill bit.
Mounting this unit on tile requires the use of anchors. Special care must be taken not to crack the tile. Before drilling holes in
the tile, lightly chip glazed surface of tile at the desired locations. Drill holes using a 3/16" masonry drill bit. Insert anchors into
the holes making certain that ring on large end of anchor meets the surface of the tile.
CLEANING
SEALING
Seal unit by caulking along outside of enclosure where metal and bath meet, especially where sill meets threshold. If desired,
caulk inside of enclosure where jambs meet walls.
Cleaning and care of your enclosure is important to its lasting beauty. A nonabrasive liquid cleaner is recommended.
Never use scouring powder or pads.
CAUTION
Do not attempt to cut mirrors or glass used in this enclosure. Tempered glass and mirrors will shatter if cut.
Care should be taken when standing raw glass on its edge. Glass may shatter if corners are bumped or edge is rested on
a rough floor surface. Cardboard, wood blocks, or a similar surface is a safe resting surface for glass.
