713C-GP 8/06
KEY DESCRIPTION PART QTY
A SILL A195 1
B PIVOT JAMB A196 1
C STRIKE JAMB A194 1
D VINYL DRIP RAIL V667 1
E DRIP RAIL TAPE (I) HT52 1
H MAGNETIC STRIP H172 1
J PIVOT DOOR SLIDE BLOCK (I) HPT3 2
W PIVOT VINYL (I) V517 1
G ALUMINUM PIVOT PLATE (I) HAPP 2
S 8A X 1 1/4 FLAT HEAD SCREW (I) H810 6
K PIVOT PIN (I) HPHD 2
I DRIP RAIL PLUG HA28 1
L PIVOT BUSHING HBPB 2
M 8-32 X 1/2 HEX HEAD SCREW HP05 2
P ANCHORS H002 8
Q 8A X 1 1/4 FLAT HEAD SCREW H810 2
F 8A X 2 FLAT HEAD SCREW H462 6
O** PULL HANDLE KIT ** HSAD 1
6-32 X 1 1/4 PAN HEAD SCREW H485 2
EXTERIOR PULL HANDLE HA31 1
INTERIOR PULL HANDLE HA32 1
Before starting installation of your new enclosure, carefully read all instructions
and lay out parts to become familiar with their identity.
USE OF ANCHORS
Anchors are furnished with every enclosure. However, the use of anchors is not recommended when attaching your enclosure
to a fiberglass unit or wall surrounds with board reinforced mounting areas. Mounting holes in this case should be drilled with
an 1/8" drill bit.
Mounting of this unit on tile requires the use of anchors. Special care must be taken not to crack the tile. Before drilling holes
in the tile, lightly chip glazed surface of tile at the desired locations. Drill holes using a 3/16" masonry drill bit. Insert anchors
into the holes making certain that ring on large end of anchor meets the surface of the tile.
CLEANING
SEALING
The use of a caulking compound can assure a water-tight seal when applied along outside edge of the enclosure where metal
and bath meet. If desired, caulk inside of enclosure where jambs meet walls.
C leaning and care of your enclosure is important to its lasting beauty. We suggest using a nonabrasive liquid cleaner.
Never use scouring powder or pads.
Do not try to cut the mirrors or glass used in this enclosure.
Tempered glass and mirrors will disintegrate if cut.
PARTS LIST
(I) Pre-Installed ** May Be Preinstalled
TOOLS
NEEDED
1/8" Drill Bit
3/16" Drill Bit
(3/16" Masonry Bit for
Ceramic Tile)
Pencil
Measuring Tape
Hacksaw
Phillips Screw Driver
Silicone Caulk
File
Drill
Level
Masking Tape
FRAME PACKAGE
HARDWARE BAG
