Qe a – Coral Industries 6000 Pivot Door with Adjustable Jambs - 763R User Manual
Page 3
763R / 713R -GP 4/06
OUTSIDE OF SHOWER
8A x 3/8 Pan Head Self-Drilling Screw
(H900 - Used for Pivot Plates and to attach
Strike Jamb to Adjustable Jamb)
N
8-32 x 1/2 Hex Head Screw
(HP05 - Used for Pivot Door
Slide Block)
M
8A x 1 1/4 Flat Head Screw
(H810 - Used for Jambs)
Q
6-32 x 1 1/4 Pan Head Screw
(H485 - Used for Handle)
O
A960
PIVOT JAMB
A730
STRIKE
JAMB
H485
PAN HEAD
SCREW
HA32
INTERIOR
HANDLE
HW81
NYLON WASHER
A263
SILL
H170
MAGNETIC
STRIP
HSAD
PULL HANDLE
KIT
V517
PIVOT
VINYL
H810
FLAT
HEAD
SCREW
HP05
HEX HEAD
SCREW
HA65
PIVOT
PLATE
HPHD
PIVOT
PIN
HPT3
PIVOT DOOR
SLIDE BLOCK
A710/V667
DRIP RAIL
H810
FLAT
HEAD
SCREW
L
A265
ADJUSTABLE
JAMB
H900
PAN HEAD SELF-
DRILLING SCREW
Q
E
A
HT52
DRIP RAIL
TAPE
D
VS91
DRIP RAIL VINYL SWEEP
H002
ANCHORS
HA28
DRIP
RAIL
PLUG
P
I
HA31
EXTERIOR
HANDLE
C
R
O
M
K
J
N
G
W
Q
H
B
H900
PAN HEAD
SELF-
DRILLING
SCREW
N
F
