Copernicus IS2 User Manual
Page 7
IS2 - Version A - Released 02 August 2013 - Copernicus Educational Products Inc.
4
Install Whiteboard Supports
Whiteboard Supports
x 2
You will need:
(Not to Scale)
x 4
x 4
Actual Size:
B
G
2 Person Task
Left
Whiteboard Support
Right
Whiteboard Support
Mounts
at outer hole
on bottom
!
Left Side
Left Side
Right Side
Top Mounting hole
Top Mounting hole
!
Fasten bottom
bolts first
G
B
7
