Angle the rack
into position
Snap
15
Install Front Tub Rack
?
Identify Tub Rack orientation
?
Angle the Front Tub Rack into the Front Channel.
?
Press down firmly to snap into place.
?
Once installed, rack should slide smoothly in
channel.
Front Tub Rack x 1
You will need:
(Not to Scale)
Back bar rests on top
UP
!
16
Install Tub Channels
Tub Channel x 4
You will need:
(Not to Scale)
x 12 x 12 x 12
E F H
Actual Size:
There are 5 different channel
placement options. Choose
positions for the channels that
will organize the tubs best for
you.
You may always upgrade the
Standard Inspiration Station to
the Premium model if you
need more tubs. See our
website for more information. Fasten middle bolt first,
this will make the other
two bolts easier to
!
Top
Bottom
!
H
E
F
14
