16
A. REPLACE MICROPHONE
B. PLUG MICROPHONE IN
SECURELY
C. CHECK WIRING
D. CALL PSE FOR LIST OF
ADAPTABLE MICROPHONES
PROBLEM PROBABLE CAUSE REMEDY
NO SIREN OUTPUT.
EXTERNAL 20A
FUSE BLOWS.
A. AMPLIFIER POWER WIRES REVERSED
POLARITY
NO OUTPUT FROM
SPEAKER, TONES
HEARD INSIDE
AMP. MODULE.
A. SPEAKER NOT CONNECTED/ OPEN
CIRCUIT IN SPEAKER WIRING
B. DEFECTIVE SPEAKERS
SIREN TONES
VOLUME TOO
LOW/GARBLED.
A. LOW VOLTAGE TO SIREN AMPLIFIER
B. HIGH RESISTANCE IN WIRING/DEFEC-
TIVE SPEAKER
C. SPEAKERS PHASED IMPROPERLY
A. CHECK CONNECTIONS
A. CHECK POLARITY
B. REPLACE SPEAKER(S)
A. CHECK SPEAKER WIRING
B. REPLACE SPEAKER(S)
A. CHECK WIRING FOR BAD
CONNECTIONS/ CHECK VE-
HICLE CHARGING SYSTEM
B. CHECK SPEAKER(S) WIR-
ING/REPLACE SPEAKER(S)
C. REFER TO PAGE 5 FOR
PROPER PHASING
HIGH RATE OF
SPEAKER FAILURE.
A. VEHICLE BATTERY VOLTAGE TOO HIGH
B. 58 WATT SPEAKER CONNECTED TO 100
WATT TERMINAL.
A. CHECK VEHICLE CHARG-
ING SYSTEM
B. USE CORRECT SPEAKER
C. CHECK TERMINALS
SIREN CONTINUES
TO OPERATE FOR
7 SEC. AFTER
MANUAL BUTTON/
HORN RING IS RELEASED.
A. "HIT-N-GO" FEATURE ENGAGED. NOR-
MAL OPERATION
INTERCLEAR WILL NOT
POWER AUXILIARY DE-
VICES.
A. THERE IS A SHORT IN THE WIRING, OR
THE LOAD IS GREATER THAN 1 A.
A. CHECK FOR SHORTS. IN-
STALL INTERCLEAR BOOST-
ER KIT (PART #INTBS)
P.A. VOLUME LOW OR NO
P.A. AT ALL. VOLUME CON-
TROL FULLY CLOCKWISE.
A. DEFECTIVE MICROPHONE
B. MICROPHONE NOT COMPLETELY
PLUGGED IN.
C. COMMON MICROPHONE CIRCUIT NOT
PROPERLY WIRED.
D. INCORRECT MICROPHONE.
TROUBLESHOOTING
(Refer to wiring diagram page 20)
A. SHORTED SPEAKER OR SPEAKER
WIRES. SIREN IN OVER CURRENT PRO-
TECTION MODE.
