11
CABLE AND RECONNECT AS SHOWN ABOVE.
6 WIRE, SHIELDED CABLE (COMMON MIC ONLY)
RRB ADJUSTMENT
LIGHT BAR CABLE GROUND
S-1
20 A.
CIRCUIT
S-6
2-WAY RADIO
CIRCUIT (OPTIONAL)
S-8
INTERCLEAR
S-7
SPEAKER
OPTIONAL 2nd 100W SPEAKER FOR 200W
S-5 S-3
HORN RING
S-2
BREAK MIC HI, MIC LO, & PTT WIRES IN RADIO CONTROL HEAD TO TRANSMITTER
12 GA.
12 GA.
12 GA.
10 GA.
12 GA.
30 A.
20 A.
T-1
10 GA.
T-11
T-7
T-9, LIGHTING LEVEL 2 T-10, LIGHTING LEVEL 3 T-8, LIGHTING LEVEL 1 T-6, ACCESSORY D T-4, ACCESSORY A T-5, ACCESSORY B T-3, ACCESSORY C
