17
Replacement Parts
Central Controller
S25808 – Central Controller in Enclosure with Power Harness and Control Harness
Complete 3x5s with Lens, Silicon Seal & Deutsch Connector
S25809 – Split-Warning 3x5 with Amber Lens, Silicon Seal, & Deutsch Connector
S25810 – Reverse 3x5 with Clear Lens & Silicon Seal
S25811 – STT (Stop-Turn-Tail) 3x5 with Red Lens & Silicon Seal
Lens with Silicon Seal
S25803 – Clear Lens with Silicon Seal
S25804 – Red Lens with Silicon Seal
S25805 – Blue Lens with Silicon Seal
S25806 – Amber Lens with Silicon Seal
XT-3 with Deutsch Connector & Mounting Bracket
S25815 – Amber XT-3 with Whelen Bracket
S25816 – White XT-3 with Whelen Bracket
S25817 – Amber XT-3 with Code 3 Bracket
S25818 – White XT-3 with Code 3 Bracket
Harnessing
T16585 – Control Cable, 5 Wire, 16 AWG, 10 Feet
T16586 – Power Cable, 2 Wire, 12 AWG, 15 Feet
T16587 – Overhead Lighting Cable, 5 Wire, 16 AWG, 40 Feet
T16624 – Overhead Lighting Cable, 5 Wire, 16 AWG, 20 Feet
T16588 – Side (XT-3) Lighting Cable, 2 Wire, 16 AWG, 20 Feet
T16625 – Side (XT-3) Lighting Cable, 2 Wire, 16 AWG, 40 Feet
T16612 – Rear (3x5) Lighting Cable, 3 Wire, 16 AWG, 40 Feet
T16615 – Rear (3x5) Lighting Cable, 3 Wire, 16 AWG, 20 Feet
Install Manual
T56825 – Matrix System Installation Manual
