C. N2O Configuration Examples

The following are examples of settings to achieve the various nitrous triggering configurations described in Section A
above:

1. Button only: Activate nitrous

only when the button is pressed.

Fuel TPS RPM Btn

040 OFF OFF

N2O

Set: TPS to OFF, RPM to OFF, and Btn to

N2O.

2. TPS only: Activate nitrous only

when the Throttle is pressed
beyond a set level.

Fuel TPS RPM Btn
040

200 OFF OFF

Set: TPS to ON (set the TPS threshold to the

desired level), RPM to OFF, Btn to OFF.

3. TPS and RPM only: Activate

nitrous only when the Throttle is
pressed beyond a set level AND
when RPMs are with a certain
range.

Fuel TPS RPM Btn
040 200

ON OFF

Set: TPS to ON (set TPS threshold to desired

level), RPM to ON (set Min/Max to
desired levels), Btn to OFF.

4. Button (N2O) or TPS: Activate

nitrous when button is pressed or
when Throttle is pressed beyond a
set level.

Fuel TPS RPM Btn
040 200 OFF

N2O

Set: TPS to ON (set TPS threshold to desired

level), RPM to OFF, and Btn to N2O.

5. Button (N2O) or TPS and RPM:

Activate nitrous when button is
pressed or when Throttle is
pressed beyond a set level AND
the RPMs are within a certain
range.

Fuel TPS RPM Btn
040 200 ON

N2O

Set: TPS to ON (set TPS threshold to desired

level), RPM to ON (set Min/Max values),
and Btn to N2O.

6. Button (ARM) and TPS:

Activate nitrous when button
input is on (armed) AND Throttle
is pressed beyond a set level.

Fuel TPS RPM Btn

040 200 OFF

ARM

Set: TPS to ON (set TPS threshold to desired

level), RPM to OFF, and Btn to ARM.

7. Button (ARM) and TPS and

RPM: Activate nitrous when
button input is on (armed) AND
Throttle is pressed beyond a set
level AND the RPMs are within a
certain range.

Fuel TPS RPM Btn

040 200 ON

ARM

Set: TPS to ON (set TPS threshold to desired

level), RPM to ON (set Min/Max values),
and Btn to ARM.
