Revised 05-07-07 Page 3 of 16
IV. Control Box Operation
The control box is powered only when the injectors are on which occurs for a few seconds when the key is first turned on
or when the engine is running. Up to 5 different fuel adjustment maps are stored in the box (currently all with zero values).
The box will remember what map was last selected and what its settings are – you do not need to do anything to save a
map when making adjustment (see Fuel Adjustments below).
A. Intro / Startup Screen
When the box is first turned on (by the engine or battery), the Intro screen is displayed. Press any key to go to the main
menu. An example Intro screen display is shown below:
Apex Turbo 1000
5B5jBD N2O:FIX
In the example shown above, this screen displays the following information:
Apex Turbo
Sled model. This box is designed for the Yamaha Apex. Boxes for other sleds will
have other lettering.
5B5jBD
This is the software version of the box. The box can be reprogrammed only by sending
the box back to Boondocker
N2O:
Shows that this Control Box is nitrous capable.
FIX
Nitrous pressure regulator type (refer to Nitrous Section for more description)
B. Main Menu
The Main Menu is shown below:
Main
Æ
Fuel Stats
Menu N2O Map1U
The current selection is shown by the Right-Arrow and the cursor (underscore below the “F”). Use the arrow keys to
move the cursor. Move the cursor to the desired selection and press the “SEL” key to select the desired menu option from
one of the following:
Fuel Go to the Fuel adjust menus (see Section 1).
Stats Display runtime data, captured data, and recorded maximum data (see Section 3).
N2O Menus for optional Boondocker Nitrous kit (see Chapters VII and IX..).
Map Go to the Map menu (see Section 2)
The current Map number is displayed as “Map1U”. This indicates that map number 1 is being used and it is Unlocked.
1. Fuel Adjust Menus
This selection is used to make fuel adjustments. There are four Fuel adjust screens (examples shown below). The first
screen comes up after selecting Fuel.
Go to the next screen by pressing the “SEL” button. After pressing the “SEL” on the last Fuel adjust screen, you will
return to the Main Menu. Use the Left/Right Arrow keys to switch between settings. Use the Up/Down Arrow keys to
change the settings. Sample Fuel adjust screens are shown below (actual rpm settings and number of screens may be
different for your model).
