16
CARE AND CLEANING
Ensure the JE 4011 Juice Extractor is turned
off by pressing the ‘On/Off ’ button on
the control panel to ‘Off ’. Then switch the
appliance off at the power outlet and unplug
the cord.
Ensure the JE 4011 Juice Extractor is correctly
disassembled. Refer to Disassembling your JE
4011 Juice Extractor (16 - 17).
FOR EASIER CLEANING:
Clean as you go and avoid dried on juice or
pulp residue.
Immediately after each use, rinse removable
parts in hot water to remove wet pulp. Allow
parts to air dry.
To minimise cleaning, line the pulp container
with a plastic freezer bag to collect the pulp.
Pulp can then be used in other dishes (see
recipes section R8 - R9) or as compost for the
garden or discarded.
NOTE
Cleaning the motor base
1. Wipe the motor base with a soft, damp
cloth then dry thoroughly.
2. Wipe any excess food particles from the
power cord.
Do not use abrasive scouring pads or cleaners
when cleaning the parts or motor base as they
may scratch the surface.
NOTE
Cleaning the fi lter bowl surround, juicer
cover, Puree insert, food pusher, pulp
container
1. Wash all parts in warm soapy water with
a soft cloth. Rinse and dry thoroughly.
The fi lter bowl surround, juicer cover and pulp
container are dishwasher safe (top shelf only).
The Puree insert is not dishwasher safe.
Please wash in warm water.
NOTE
Cleaning the juice disc
For consistent juicing results always ensure
that the juice disc is thoroughly cleaned
using the supplied cleaning brush.
1. Soak the juice disc in hot soapy water for
approximately 10 minutes immediately
after juicing is completed. If pulp is left to
dry on the fi lter it may clog the fi ne pores
of the fi lter mesh thereby lessening the
eff ectiveness of the juicer.
2. Using the cleaning brush, hold the juice
disc under running water and brush from
the inside of the basket to the outer rim.
Avoid touching the small sharp blades in
the centre of the juice disc. After cleaning
the juice disc, hold it up towards a light
to ensure the fi ne mesh holes are not
blocked. If the holes are blocked, soak
the juice disc in hot water with 10%
lemon juice to loosen the blocked holes.
Alternatively, wash the juice disc in the
dishwasher.
The juice disc is dishwasher safe (top shelf only).
NOTE
CARE AND CLEANING
