Catler JE 4011 - Manual (Page 12)

10
ASSEMBLING YOUR JE 4011 JUICE EXTRACTOR
Step 5
Raise the safety locking arm up and lock into
the two grooves on either side of the juicer
cover. The safety locking arm should now be
in a vertical position and locked into place on
top of the juicer cover. Step 6
Slide the food pusher down the feed chute
by aligning the groove in the food pusher
with the small protrusion on the inside of the
top of the feed chute.
There is no need to use pulp container when
using Puree Extractor.
NOTE
Step 7
Place the juice jug provided under the spout
on the right-hand side of the JE 4011 Juice
Extractor. The juice jug lid can be used to
avoid any splatter.
