8
ERROR CONDITION WHERE TO LOOK FOR CAUSE
High or Low Oil Pressure Oil Pump - Pressure Regulator Valve Stuck.
- P/R Retainnig Ring not fully seated in groove
- Orifice hole in P/R Boost Valve sleeve plugged.
Oil Filter - Cracks in Filter Intake Tube.
- Intake Tube Seal Damaged.
- Wrong grease used on reassembly (clogging filter).
Valve Body Assembly - Spacer Plate or Gaskets misassembled or damaged.
- Check Balls omitted or mislocated.
- Wrong grease used on reassembly (clogging Solenoid
Filter.)
Harsh Shifts
Valve Body Assembly - Wrong holes drilled.
- Separator Plate or gaskets misassembled or damaged.
- Check Balls omitted or mislocated.
Inconsistent Shift Points Valve Body Assembly - Separator Plate or gaskets misassembled or damaged.
External Linkage - Manual Shift Lever Linkage misadjusted.
No or Slips in 1st Gear 1-2 Accumulator - Damaged or missing piston seal.
- Incorrect spacer(s) holding piston above case surface.
Low Oil Pressure - (See above)
Valve Body Assembly - Spacer Plate or gaskets misassembled or damaged.
- Check Balls omitted or mislocated,
- Solenoid disconnected or damaged,
- 2-4 Band Anchor missing
No or Slipping 2-3 Shift Valve Body Assembly - Spacer Plate or gaskets misassembled or damaged.
- Solenoid disconnected or damaged.
- Spacer Plate or gaskets misassembled or damaged.
No or Slipping 3-4 Shift Valve Body Assembly - Spacer Plate or gaskets misassembled or damaged.
- Solenoid disconnected or damaged.
- Spacer Plate or gaskets misassembled or damaged.
3-4 Accumulator - Damaged or missing piston seal,
No or Slipping Reverse Valve Body Assembly - Spacer Plate or gaskets misassembled or damaged.
Oil Pump
- P/R Retaining Ring not fully seated in groove.
No TCC Apply TCC Solenoid - Solenoid disconnected or wiring damaged.
TOOL LIST
1 3/8" drive ratchet wrench
1 3/8" torque wrench
1 2"-6" 3/8" drive extension
1 8, 10, 13mm Sockets
1 8, 10, 13mm combination wrench
1 8" Plain Screwdriver
1 Small Internal Retaining Ring Pliers
1 Needle nose pliers
1 Hammer
1 Gasket scraper
1 3/8" Drill motor
1 Fine cut fiat file
1 Wet or Dry sand paper
PARTS LIST
1 Pan Gasket
1 Upper Valve Body Gasket
1 Lower Valve Body Gasket
2 Snap in Solenoid Filters Aluminum Plug
1 GREEN Press Regulator Spring
1 Press Regulator Retaining Ring
1 3/8"x 5/16" ID RED Spacer
1 1/2"L x 5/16" ID GREEN Spacer
1 5/8"L x 5/16" ID YELLOW Spacer
1 3/4"L x 5/16" ID BLUE Spacer
1 19/32"L x 1/4" ID VIOLET Spacer
1 3/8"L x 1/4" ID WHITE Spacer
1 3/32" (.094) Drill 1/8" (.125) Drill
1 1/2" x 1" x 2" Anvil Plate
