46
Name Function
(2) Channel status table Display the channel’s status information. Use
×Ø
can scroll up and down the channel
status table.
When camera is connected, the record, motion, and GP status will be indicated by figure
icon.
(3) Channel Info
Display the name, IP address, model of selected channel and current date and time that
user has selected from (2) Channel status table.
(4) Configuration To add/delete the camera, setup the recording schedule, motion detection, and other
related parameters of the camera(see also Chapter 4.3 )
(5) Split screen mode Click to select the split screen mode – 6, 8, 13, 16, 17, 25, 28, 36, 49, 64-split screen mode.
Using the
ÂÁ
to go next or previous page.
(6) Playback
Click to call out the IP Player to playback the recorded file by IPCamCenter(see also
Chapter 4.4 )
(7) 9-split screen mode Switch to 9-split screen mode.
(8) Record All
Click to enable recording for all channels. When the recording is enabled, the recording
status light of the channel will turn ON.
(9) QUAD screen mode Switch to 4-split screen mode
(10) Auto Scan Start/Stop video screen cycle switch
(11) Single screen mode Switch to single camera mode.
(12) Full screen
Use the entire area of the screen to only display the video. To return, press ESC on the
keyboard.
(13) Speaker
Enable/disable speaker.
(14) Audio ON/OFF
Click to turn on/off the audio sound play.
(15) Record
Enable/disable recording of the selected channel. When the recording is enabled, the
recoding status light of the channel will turn ON.
(16) Snapshot Capture the current video screen.
(17) PTZ control When the camera is a PTZ camera, use the PTZ control to move the lens of the camera.
(18) Minimize Click to close the IPCamCenter to the system tray.
(19) Exit Close the IPCamCenter application.
Recording Status:
- Light up: Recording ON
- Light Off: Recording OFF GP Input:
- Light up: YES
- Light Off: NO
Motion Detection:
- Light up: ON
- Light Off: Disable
