43
Chapter 5 Backup Recorded Video File
HDD Backup application provides user an interface to view recorded video from hard disk
and backup it.
5.1 Familiarizing with HDD Backup Application
Name Function
(1) Date Select the date for events
(2) Hour and Channel User can select the hour and channel for events.
: All events in this hour and channel have been selected.
: In this hour and channel has events
: Partial of events in this hour and channel has been selected.
(3) Event list All recorded video events list
No.: the list order number
Record: the record type(see also Chapter 2.4 )
Begin Time: the beginning of record time
End Time: the end of record time
(4) Set Marked File Use Ctrl and mouse to select the multiple events from event list, and then
click Set Marked File to mark multiple events. When click Set Marked File
button, the marked event will turn to un-mark and un-mark event will turn to
marked.
(5) Page Switch
Pre: go back last page
Next: go to next page
Page column: enter the page number and click Go button to go to the page
(6) Select All Select all listed recorded video events. Click the check box again to cancel
for selecting all events.
(7) Video display Display first frame of each recorded video channel from 4 selected.
