12
Chapter 2 Operating the DVR unit
2.1 Familiarizing the Remote Control Buttons
Use the Remote control to operate the OSD menu on surveillance screen.
Button Function
(1)
- Press + 0 , the DVR system will
instantly playback the recorded file that is
recorded 60 seconds before.
- In multiple DVR mode, press +
number button( ~ ) can switch to
the selected DVR.
(2)
As a Channel 1 in preview and playback mode
As a channel 1 and preset position in PTZ mode
(3)
As a Channel 2 in preview and playback mode
As a channel 3 and preset position in PTZ mode
(4)
As a Channel 3 in preview and playback mode
As a preset position in PTZ mode
(5)
As a Channel 4 in preview and playback mode
As a preset position in PTZ mode
(6)
Switch to QUAD mode in preview and playback
mode
As a preset position in PTZ mode
(7)
As a channel 2 in PTZ mode
As a preset position in PTZ mode
A s a channel 4 in PTZ mode
As a preset position in PTZ mode
As a preset position in PTZ mode
As a preset position in PTZ mode
(8)
To enter the OSD Main menu
Exit from the main menu or sub-menu display
Button Function
(9) To move up the selection and select the items in the menu list or change the settings.
(10)
Make a selection To play the video
Enter sub-menu
(11) To move the selection to the left
(12) To move the selection to the right
(13)
To move down the selection and select the items in the menu list or change the
settings
.
(14) Start video recording
