Alumax W1 User Manual
Page 16
6
5
6
INSTRUCTION MANUAL
16
13 DOOR GASKETS
5
5
6
6
Temporarily install midgasket (5) and the door
gasket (6) to door panel.
Close door entirely, mark interference of gaskets with
running rail.
Cut gasket at marked locations with cutters. Note
w
o
l
e
b
t
u
c
e
b
o
t
y
l
n
o
s
d
e
e
n
)
5
(
t
e
k
s
a
g
d
i
m
t
a
h
t
running rail. The top part is no longer required for
assembly.
Reinstall gaskets from bottom working your way
up. Use a mallet to insure that the gaskets are fully
pushed onto glass panel door.
13a
13a
13b
13b
13c
13d
13c
13d
REMOVE GASKET FROM
PANEL BEFORE CUTTING.
INTERIOR
SHOWER SIDE
INTERIOR
SHOWER SIDE
