Close-up lens
450C-8-2
Close-up lens
240C-8
Accessories
Close-up Lens C-8
The viewfinder is a single lens reflex type and has
no parallax so that even in close-ups you can film
just what you see. The Close-up Lens C-8 is
specially designed for this 8mm camera and
completely compensates chromatic aberration. If
you screw this lens into the tip of lens, it in­
creases power for titles, copying literature,
filming plants, insects and so on. It is easy to use
and convenient for the sky, and elusive small
animals, since you can take close-ups from a
distance. Distance adjustment is also easy.
* 58mm indicates the screw diameter, and 240 or
450 indicate the focal length. A subject that is
240mm (or 450mm) away from the tip of the lens
will be in focus.
Shooting Distance and Field of View
58mm Close-up C-8
Type
Focusing Distance
of Zoom Lenses
Distance Scale in
the Focusing Ring
Distance from Subject
to Film Plane
Field of View Comparable Size
450
7.5mm
oa 609mm 339x251mm B4
1 2m 475mm 224x166mm Between B5 and A5
60mm
00 609mm 45x33mm Large size stamp
1,2m 475mm 30x22mm Stamp size
240
7.5mm
00 394mm 179x132mm B6
1 2m 353mm 138x102mm A4
60mm
» 394mm 24x17mm Half size
1,2m 353mm 18x13mm Thumb nail
