Light output index windows
Used in M mode
Flash mode indicators
Aperture index window
Used in A mode
Flash mode selector
.... u TTI mode—for
p i u y i a i i i i i i y j
1
| | _
Film speed scale window
■ ■
Film speed index
Film speed knob
Flash shooting distance range
indicators
The patterned bar (fourth bar from
the top) shows programmed TTL
auto flash information.
Distance scale window
Distance scale selector
Power switch
See page 33.
Open-flash button
For (l) test firing in A mode, (2) multiple
flash exposures (page 42) and (3) to turn on
SB-20 after it is automatically turned off
(page 33).
READY BOUNCE
■
KBFVnìB
TTL auto flash
operation
M mode—for
manual flash
operation.
Aperluie index knob/iight output
selector knob
Used in A and M modes
Bounce set indicator
Lights up when flash head is rotated.
Ready-light
See page 34.
