CRAFTSMAN TABLE SAW - MODEL NO. 315.228390
The model number will be found on a plate attached to the cabinet. Always mention the model number in all correspondence regarding your TABLE
SAW or when ordering repair parts.
PARTS LIST FOR FIGURE 1
KEY PART KEY PART
NO. NUMBER DESCRIPTION QUAN. NO. NUMBER DESCRIPTION QUAN.
1 ** STD551131 * Lock Washer (5/16 in.).................. ........... 6 27 ** STD511003 * Screw (#10-24x3/8 in.)................ ..........2
2 ** STD523105 * Bolt(5/16-18x1/2in. HexHd,).. ...........2 28 980946-001 * Washer (#10)............................... ..........2
3 979880-001 Blade Guard Bracket.................... ...........1 29 979908-001 Bracket ........................................ ..........1
4 979883-001 * Bolt (1/4-20)................................... ...........1 30 979911-001 Bevel Scale Indicator................... ..........1
5 979884-001 Spring........................................... ...........1 31 979914-001 Knuckle........................................ ..........1
6 980600-001 Washer......................................... ...........1 32 980589-001 Retaining Ring............................. ..........1
7 979886-001 Table Bracket................................ ...........2 33 979924-001 Height Adjustment Rod............... ..........1
8 980588-001 Star Washer.................................. ...........6 34 979923-001 “0” Ring........................................ ..........2
9 ** STD523110 * Bolt(5/16-18x1 in. HexHd.)............ ......... 10 35 979922-001 Washer......................................... ..........1
10 979896-001 Retaining Ring.............................. ...........2 36 979897-001 Cradle (Trunnion)........................ ..........1
11 979895-001 Ball Bearing (6202Z).................... ...........2 37 979898-001 Arbor Housing.............................. ..........1
12 979894-001 Key................................................ ...........1 38 979902-001 Washer......................................... ..........1
13 979893-001 Arbor Shaft.................................... ...........1 39 979903-001 Retaining Ring............................. ..........1
14 10 in. Blade (Item No. 9 32126) .. ...........1 40 ** STD304420 V-Belt (4L-420)............................. ..........1
15 979891-001 Outer Blade Washer..................... ...........1 41 979900-001 Pulley........................................... ..........1
16 979890-001 Blade Nut...................................... ...........1 42 ** STD502502 * Setscrew (1/4-20 x 1/4 in.)............ ..........4
17 979889-001 Blade Wrench............................... ...........1 43 980593-001 Retaining Ring............................. ..........1
18 979906-001 Shaft............................................. ...........1 44 ** STD523107 * Bolt (5/16-18x3/4 in. Hex Hd.).. ..........2
19 979907-002 Bevel Lock Handle....................... ...........1 45 979925-001 Motor Support Base..................... ..........1
20 979912-001 * Washer (#8)................................... ...........5 46 979926-001 Spring.......................................... ..........1
21 979910-001 * Screw (#8-32 X 3/8 in.)................. ...........5 47 979904-001 Retaining Ring............................. ..........2
22 979917-001 Threaded Rod............................... ...........1 48 979927-001 Pivot Shaft................................... ..........1
23 979915-001 Bracket......................................... ...........1 49 979928-001 Screw........................................... ..........1
24 979905-001 Spring .......................................... ...........1 50 979929-001 Motor Mounting Plate.................. ..........1
25 979904-001 Retaining Ring.............................. ...........1 51 ** STD541031 * Hex Nut (5/16-18)........................ ..........4
26 979885-001 Washer......................................... ...........1 52 ** STD551031 * Washer (5/16 in.)......................... .......... 8
972000-780 Cwner’s Manual
* Standard Hardware Item — May Be Purchased Locally ** Available From Div. 98 - - Source 980.00
*** Complete Assortment Available At Your Nearest Sears Retail Store
