ORAFTSMAN 4-CYOLE EÍ6INE MODEL NO. 143 J5Í002
Ref.# Part# Part Name Ref,
#
Part
#
Part Name
1 36478A Cylinder (Irtcl. 2, 7, 20 & 125) 150 3B991 Valve Spring
2 26727 Dowel Pin 151 31673 Valve Spring Cap
6 33734 Breather Element 169 27234A Valve Cover Gasket
7 36557 Breather Body Ass’y. (Inci 6
&
12) ■ 172 32755 Vaive Cover
12 Breather Cover & Tube (Incl 12B) 174 30200 Screw, 10-24 x 9/16“
12B 34695 Breather Tube Elbow 178 29752 Nut & Lock Washer, 1/4-28
14 28277 Washer 179 30593 Retainer Clip
IS 30589 Governor Rod (ind 14) 182 6201 Screw, 1/4-28
X
7/8"
16 31383A Governor Lever 184 26756 Carburetor To intake Pips Gasket
31335 Governor Lever Clamp 185 31384A Intake Pipe (Incl. 224)
18 650648 Screw, 8-32 x S/16" 186 34337 Governor Link
19 36281 Extension Spring 200 35727 Control Bracket (Ind , 202 thru 206)
20 32600 Oil Seal 202 36482 Compression Spring
30 36231 Crankshaft 203 31342 Compression Spring
40 36073 Piston, Pirr & Ring Set (Std.) 204 650549 Screw, 5-40 x 7/16"
40 3B074 Piston, Pin & Ring Set {.010" OS) 205 650777 Screw, 6-32
X
21/32“
40 36075 Piston, Pin & Ring Set {,020" OS) 206 610973 Terminal
41 36070 Piston
&
Pin Ass’y {Std.) {incl. 43) 207 34336 Throttle Link
41 36071 Piston & Pin Ass’y, {.010" OS) (ind. 43) 209 30200 Screw, 10-24 x 9/16"
41 36072 Piston
&
Pin Ass’y {.020" OS) (Ind, 43) 215 32410 Control Knob
42 36076 Ring Set (Std ) 223 650451 Screw, 1/4-20
X
1"
42 36077 Ring Set C010" OS) 224 34690A----- Intake Pipe Gasket
42 OCSriTCi
ijOxJ f ij
Ring Set
{
020" OS) 23S 650932 Screw, 10-32
X
49/64"
43 20301 Piston Pin Retaining fling 239 O rfOQQ Air Cleaner Gasket
45 30963B Connecting Rod Ass'y, {1nci 46) 241 35797 Air Cleaner Collar
46 3261OA Connecting Rod Boil 245 36066 Air Cleaner Filter
48 27241 Valve Litter 250 35065 Air Cleaner Cover
SO 35992 Camshaft (MGR) 260 36420A Blower Housing
52 29914 Oil Pump Ass'y. 261 30200 Screw, 10-24
X
9/16"
69 35261 Mounting Flange Gasket dod 650831 Screw, 1/4-20 x 1/2*
70 36248A Mounting Flange (Incl 72 thru 83) 275 36456A Muffler (Ind 277)
72 30S72 Oil Drain Plug 275A 36424 Spark Arrestor Muffler (Optional)
72A 28534 Oil Drain Plug 276 OO / 0 w
Locking Plate (Optional)
73 28833 Drain Plug Gasket 277 650980 Screw, 1/4-20
X
2-5/16"
7S 27897 Oil Seal 277A 650795 Screw, 1/4-20 x 2-1/4" (Optional)
80 30574A Governor Shaft 285 35000Á Starter Cup
81 30590A Washer 287 650926 Screw, 8-32 x 21/64"
82 30591 Governor Gear Ass’y (Ind. 81) 290 34357 Fuel Line
83 30588A Governor Spool 292 26460___
-
Fuel Line Clamp
B6 650488 Screw. 1/4-20 x 1-1/4" 300 35586 Fuel Tank (Incl 292
&
301)
89 611004 Flywheel Key 301 35355 Fuel Cap
90 611112 Flywheel 306 35647 Oil Fill Tube
92 650815 Belleville Washer 306 34265 "0"-RJng
93 650816 Flywheel Nut 307 3S499 "0"-Ring
100 34443A Solid Slate Ignition 309 650562 Screw, 10/32
X
1/2"
101 610118 Spark Plug Cover 310 35848 Dipstick
103 650814 Screw, Torx T-15, 10-24 x 1“ 313 34080 Spacer
110 RROOA
wu&Ou
Ground Wire 327 35392 Starter Plug
119
‘
36477 Cylinder Head Gasket 370 35169 Control Decal
120 36476 Cylinder Head 370A 36261 Lubrication Decal
125 36471 Exhaust Valve (Std ) {Ind. 151) 380 632670 Carburetor (Incl. 184)
125 36472 Exhaust Valve (1/32“ OS) (Incl. 151} 390 590732 Rewind Starter
128
126
130
136 29314B
29315C
6021A
35395 intake Valve (Std) (Incl 151)
Intake Valve {1/32" OS) (Incl 151)
Screw, 5/16-18x1-1/2"
Resistor Spark Plug (RJ19LM) 400 36481* Gasket Set (Incl, items marked PK in notes)
39
