C H A P T E R
5-1
Installation and Upgrade Guide for Cisco Unified Videoconferencing 3545 MCU Releases 5.6 and 5.7
OL-17013-01
5
Technical Specifications
Table 5-1 Cisco Unified Videoconferencing 3545 Chassis Technical Specifications
Chassis Dimensions • Height: 2U (3.5 inches or 88.9 mm)
• Width: 17.25 inches (438.15 mm)
• Depth: 10 inches (254 mm)
• Weight: 8 kg (17.64 lbs) empty, 11 kg (24.25 lbs)
full—may vary according to configuration
Element Board Dimensions • Width: 9.19 inches (233.35 mm)
• Depth: 6.3 inches (160 mm)
RTM Board Dimensions • Width: 9.19 inches (233.35 mm)
• Depth: 3.15 inches (80 mm)
System Monitoring LED Indicators • POWER
• ALARM
• FAN
• TEMP
Board LED Indicators
Front panel • ETHERNET:
– Link
– Connection Speed
• GK Reg
• CPU High (MCU only)
• CD (gateways only)
• ALARM
• ACT
• MC (EMP only)
