2-13
Installation and Upgrade Guide for Cisco Unified Videoconferencing 3545 MCU Releases 5.6 adn 5.7
OL-17013-01
Chapter 2 Installing the Cisco Unified Videoconferencing 3545 MCU
Verifying the Package Contents
Verifying the Package Contents
Procedure
Step 1 Inspect the contents of the box for shipping damage.
Step 2 Report any damage or missing items to your Cisco representative.
Step 3 Verify the package contents for the Cisco Unified Videoconferencing 3545 MCU and Cisco Unified
Videoconferencing 3545 EMP modules. See
Table 2-2 .
Mounting the Cisco Unified Videoconferencing 3545 Chassis in
a 19-inch Rack
You can optionally mount the Cisco Unified Videoconferencing 3545 chassis in a standard 19-inch rack.
Two mounting brackets and a set of screws are included in the Cisco Unified
Videoconferencing 3545 chassis shipping box.
Warning During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly
touch the backplane with your hand or any metal tool, or you could shock yourself.
10/100 BaseT-1 LEDs The top part of the 10/100 BaseT-1 connector contains two LED
indicators. The left LED lights green when the local IP network link
is active. The right LED lights green if the connection speed is 100
Mbps, and is off when the connection speed is 10 Mbps.
SWAP RDY LED Hot Swap indication. Lights blue when the latches of a board are
unlocked and it is safe to remove the board from the chassis. Goes
off when the board is completely detached.
Table 2-1 Front Panel Components (continued)
Component Description
Table 2-2 Package Contents with Cisco Unified Videoconferencing 3545 MCU and Cisco Unified
Videoconferencing 3545 EMP
Product Contents
Cisco Unified
Videoconferencing
3545 chassis with
MCU and EMP • Cisco Unified Videoconferencing 3545 MCU module
• Cisco Unified Videoconferencing 3545 EMP module
• Guide to Cisco Conferencing Documentation
• Regulatory Compliance and Safety Information for Cisco Unified
Videoconferencing 3500 Products
• Cisco Unified Videoconferencing Software CD-ROM
• Cisco Information Package
