PARTS LIST FOR CRAFTSMAN 12-INCH BAND SAWS
MODELS 113.247210 AND 113.247310
Always order by Part Number - Not by Key Number
FIGURE 1 - DRIVE ASSEMBLY PARTS
Key
No.
Part
No. Description
1 507830 Cover, Front w/Label
2 9-26595 tBIade, Band Saw
3 41815 Tire
4 816600 Screw, SI. Hd. Set
5/16-18
X
2-1/8
5 STD582062 'Ring, Retaining 5/8
6 41711 Washer, Spring
7 805034 Bearing, Ball
8 816419-2 Wheel, Upper
9 41812 Ring, Retaining 1-3/8
10 STD541431 'Nut, Lock 5/16-18
11 STD551031 'Washer, 21/64 x 5/8 x 1/32
12 816364 Support Assembly,
Upper Wheel
15 816446 Screw, Blade Tension
3/8-16
X
10-1/4
14 816437 Knob, Blade Tension
15 816350 Plate, Support
16 808380-5 Screw, Pan Hd.
Plastite #8
X
3/4
17 816433 Frame
18 816453 Plate, Pivot Support
19 STD533110 'Bolt, Carriage High Strength
5/16-18x1
20 816464 Latch, Cover
21 816429 Cover, Rear
22 808447-2 Washer, Wave 3/8 x 3/4 x .016
23 60128 Washer, 17/64 x 5/8 x 1/32
24 STD541425 'Nut, Lock 1/4
25 805552-20
Washer 17/64 x 1 x 1/16
26 816435 Knob, 1/4-20
27 816444 Socket, Light
28 808335-2 Retainer
29 STD372252 'Bulb, Light
30 816380 Lens
31 808380-1 Screw, Pan Hd.
Plastite No. 6 x 3/8
Key
No.
Part
No. Description
32 814083-2 ★ Nut, Push 5/16
33 816352 Trunnion
34 815865-2 Screw, Hex Wash Hd.
1/4-20x5/8
35 816362 Slide Assembly, Lower
(Includes Key #32 & 33)
36 816356 Shaft, Bearing Support
37 816365 Support, Guide
38 STD502502 'Screw Soc. Set 1/4-20 x 1/4
39 808819-1 Ring, Retaining
40 STD315485 'Bearing Ball
41 814083-1 ★ Nut, Push 5/16
42 816379 Guide, Blade
43 60334 Screw, Socket Button
Cap No. 10-32x3/4
44 69059 Wheel, Drive
45 STD580103 'Key, 3/16 Sq, x 15/16
46 816387 Shaft, Lower Wheel
47 STD315238 'Bearing, Ball
48 816363 Slide Assembly, Upper
49 816349 Follower
50 816358 Nut, Heavy Square 3/8-16
51 816377 Indicator, Tension
52 STD551037 'Washer, .380 x .750 x ,03
53 816353 Spring, Blade Tension
54 816361 Lock, Slide
55 109093 Bolt. Carriage 1/4-20 x 1-3/4
56 816388 Guard, Blade
57 813786-2 Screw, Pan Cross Hd,
Type “TT” No. 8-32 x 5/8
58 9-22361 tBelt, Sanding 1/2 x 80
59 816368 Platen, Sanding
60 816606 Scale, Bevel
SP5086 Owners Manual (Not Ills,}
'Standard Hardware Item may be Purchased Locally.
tStock Item - May be secured through the Hardware Department
of most Sears Retail Stores or Catalog Order Houses.
★ If this part is removed, discard and replace with a new push nut.
