Specifications
Amplifier
Frequency response PHONO: RIAA curve
VIDEO 1/MD, VIDEO 2:40 Hz - 50
kHz«3dB
Audio soction
Input
SmwitívHy Impcdanc*
PHONO 2.5 mV 50 kilohms
VIDEO 1/MD
VIDEO 2 250 mV 50kilohms
Output VIDEO 1 /MD: Voltage 250 mV
Impedance 1 kUohm
Tone buttons BASS: Boost/Cut range: «7 dB
(100 Hz)
TREBLE: Boost/Cut range: *7 dB
(10 kHz)
Video section
Video input/output
Permissible ^gnal input level
VIDEOl,2:lJVp-p
Output signal level VIDEO 1, MONITOR: 1.5 Vp - p
Impiraance (output) 75 ohms unbalanced, negative sync
System
FM tuner section
Tuning range
Antenna terminals
FM stereo, FM/AM superheterodyne
tuner
Quartz-locked PLL digital
s)mthesizer system
87.5-108 MHz
75 ohms unbalanced
300 ohms balanced
Intermediate frequencylO.7 MHz
Sensitivity (at 50 dB quieting)
22.1dB£,7pV(mono)
42.1 dBf, 70 |iV (stereo)
Usable sensitivity 193 dBf, 5 pV (IHF)
Signal-to-noise ratio (at 75 kHz deviation)
80 dB (mono)
Separation
Selectivity
Harmonic distortion
AM tuner section
Tuning range
Antenna
75 dB (stereo)
35dBatlkHz
55 dB at 400 kHz
0.3% (mono) at 1 kHz
0.5% (stereo) at 1 kHz
Model for U.S.A.
530- 1,710 kHz (10 kHz)
531- 1,710 kHz (9 kHz)
Model for other countries
531-1,710 kHz (9 kHz)
530-1,710 kHz (10 kHz)
AM loop antenna. External antenna
terminals
Usable sensitivity
Signal-to-noise ratio
Harmonic
distortion
Selectivity
Tape Deck
AM loop antenna: 500 pV/m
(1,000 kHz)
54 dB
0.5%
38 dB (10 kHz)
S)rstem 4-track 2-chaimeI stereo
Frequency response (DOLBY NR OFF)
With TYPE n cassette (Sony
UCX-S): 30 -14300 Hz (*3 dB)
With TYPE I cassette (Sony HF-S):
30-13,000 Hz (*3dB)
Wow and flutter 0.08% WRMS (NAB)
Compact Disc
System
Laser
Wavelength
Frequency response
Harmonic distortion
General
Dimensions
Mass
Accessories supplied
Compact disc digital audio system
Semiconductor laser
780-790 nm
2 Hz-20 kHz (±1.5 dB)
Less than 0.03 % (1 kHz)
Approx. 430 X 410 X 400 mm (w/h/d)
(17 xl6V„x 15»/^ inches)
including projecting parts and
controls)
Approx. 93 kg (20 Ib 15 oz) net
AM loop antenna (1)
FM wire antenna (1)
Remote Commander RM-U541 (1)
Sony batteries SUM-3(NS) (2)
System control cord (1)
Audio connecting cord (3)
Feet (4)
Design and specifications are subject to change without
notice.
Intermediate frequency
450 kHz
